Model AS-200

Affordability. Reliability. Capability. Lightweight Tactical Ballistic Helmet for military use.

The ArmorSource AS-200 Ballistic Helmet is the most affordable ACH/MICH Shape NIJ Level IIIA protection helmet on the market today.

Offering proven fragmentation protection capabilities matched by our dedication to trim unwanted weight, the AS-200 is adaptable for use with all ArmorSource accessories, rails and shrouds and is relied on today by the U.S. Military and other military organizations worldwide.

Affordability. Reliability. Capability. Lightweight Tactical Ballistic Helmet for military use.

The ArmorSource AS-200 Ballistic Helmet is the most affordable ACH/MICH Shape NIJ Level IIIA protection helmet on the market today.

Offering proven fragmentation protection capabilities matched by our dedication to trim unwanted weight, the AS-200 is adaptable for use with all ArmorSource accessories, rails and shrouds and is relied on today by the U.S. Military and other military organizations worldwide.

High-Cut

360 View

Mid-Cut

360 View

Regular-Cut

360 View

Features

Provides increased protection against handgun bullets (9mm and .44 Magnum)

Universal shape used and accepted by most military organizations worldwide

Available in bolted and boltless versions

Proudly made in the USA

DOWNLOAD DATASHEET PDF

System Snapshot

Shape / Design
U.S. Army ACH Geometry
Shell Construction
Proprietary blend of Aramid and Composite Materials
Ballistic Protection
NIJ level IIIA 0108.01/0106.01
Fragments Protection
17 grain V50>2130 f/s (650 m/s) in accordance with MIL-STD-662F
9mm BFD / Trauma
Up to 1" at NIJ IIIA velocity in average
Certification
From an NIJ certified laboratory
Available Head Sizes
X-Small / Small / Medium / Large / X-Large / XX-Large
Available Shell Sizes
Small / Medium / Large / X-Large
Extreme Testing Conditions
Performs under temperature between 160°F (71°C) and -60°F (-51°C); Performs after 3 hours sea water immersion
Configurations
100% Boltless (Durability Verified)
Use
Law Enforcement; Patrol Units

Available Colors

Foliage Green
Olive Green
Sniper Black
Desert Tan
Coyote Brown

Available Cuts

High-Cut
Mid-Cut
Regular-Cut

Shell Info

Shell Thickness
0.4” (±0.1") / 10 mm (±2.5mm)
Finished Shell Nominal Weight*
Medium 2.7 lbs. / 1.22 kg; Large 2.8 lbs. / 1.27 Kg; X-Large 3 lbs. / 1.37 Kg

* Regular-cut shell

System Info

Finished Helmet Nominal Weight**
Medium 3.1 lbs. / 1.4 kg; Large 3.2 lbs./ 1.45 Kg; X-Large 3.4 lbs. / 1.55 Kg
Fully-Loaded High-Cut Nominal Weight***
Medium 3.2 lbs. / 1.45 Kg; Large 3.3 lbs. / 1.48 Kg; X-Large 3.5 lbs. / 1.58 Kg

** A Regular-cut helmet installed with retention and suspension systems *** Special Command configuration: the complete kit, with ASR side-rails, NVG Shroud and Operational Loop System

System Capabilities Checklist

Ballistic Performance*

NIJ Level IIIA
Fragmentation Protection
BFD / Trauma

Environmental Performance

Shock absorption *
Resistance for penetration *
Advanced Boltless Adhesive System

Compatibility & Add-ons*

Universal side-rails
NVG Mount
Operational Loop System
Counterweight
Camouflage Cover
Strap Extenders
Visor / Goggles
Communications / Ear Protection
Gas Mask
Carrying Bag

* In accordance with ArmorSource technical specifications and applicable standards

How to Fit Your Helmet

Getting the right fit is important for performance and comfort. Use a tape measure and caliper to take measurements. The wearer MUST be seated in an upright position for proper fitting. See the illustrations for correct measuring points.

NOTE: If any measurement falls on the dividing line between sizes, select the larger size.

Head Length
Head Width
Circumference

Measure completely around head

Helmet Size
Head Length
Head Width
Circumference
Small
UP TO 7¼" / 184 mm
UP TO 6½" / 162 mm
UP TO 21¼" / 538 mm
Medium
7¼" / 184 mm to 7¾" / 198 mm
UP TO 6½" / 162 mm
21¼" / 538 mm to 22½" / 573 mm
Large
7¾" / 198 mm to 8¼" / 210 mm
UP TO 6½" / 162 mm
22½" / 573 mm to 23½"/ 597 mm
Extra-Large
8¼" / 210 mm and over
6½" / 162 mm and over
23½"/ 597 mm and over

Request a Quote

With the capacity to produce between 12,000 – 30,000 units per month ArmorSource is a world leading custom contract manufacturer of ballistic helmet solutions.

Working in collaboration with industry leading ballistic materials partners, accessories manufacturers and the most demanding users in the world, our team is able to respond quickly and meet the exact demands of our customers.

Please contact us!
