Model Aire Carbon

Lightweight carbon fabric helmet designed for training and high risk outdoor activities

The ArmorSource ‘Aire Carbon’ Helmet is a non-ballistic helmet designed for use in training and high-risk outdoor activities. Providing a solution that looks and feels like the U.S. Army ACH, the Aire Carbon offers the feel and experience of real-life training scenarios while putting the users safety at the forefront.

With Blunt Impact protection that complies with the U.S. Army specifications, ArmorSource’s boltless and hole-less Aire-Carbon shell made of lightweight proprietary carbon fiber and composite materials deliver top level protection and an undressed weight of approximately 700 grams (1.55 lbs.).

Lightweight carbon fabric helmet designed for training and high risk outdoor activities

The ArmorSource ‘Aire Carbon’ Helmet is a non-ballistic helmet designed for use in training and high-risk outdoor activities. Providing a solution that looks and feels like the U.S. Army ACH, the Aire Carbon offers the feel and experience of real-life training scenarios while putting the users safety at the forefront.

With Blunt Impact protection that complies with the U.S. Army specifications, ArmorSource’s boltless and hole-less Aire-Carbon shell made of lightweight proprietary carbon fiber and composite materials deliver top level protection and an undressed weight of approximately 700 grams (1.55 lbs.).

High-Cut

360 View

Mid-Cut

360 View

Regular-Cut

360 View

Features

Identical to the ACH, LWACH, ACH GEN II and MICH helmets sizing, cuts and configurations

Extremely comfortable due to its ultra-lightweight and flexible chinstrap and pad system.

Compatible with universal NVG shroud and side-rails

Features industry leading safety technology

Hole-less shell construction provides increased user safety

Provides non-ballistic performance under extreme conditions (heat, cold and saltwater/wet activity).

Proudly made in the USA

DOWNLOAD DATASHEET PDF

System Snapshot

Shape / Design
U.S. Army ACH Geometry
Shell Construction
Proprietary blend of Carbon Fabric and Composite Materials
Environmental / Mechanical Protection / Design
Blunt Impact and Compression resistance in accordance with AR/PD 14-01; Shock Absorption and Penetration Resistance in accordance with EN-397
Certification
From an NIJ certified laboratory
Available Head Sizes
X-Small / Small / Medium / Large / X-Large / XX-Large
Available Shell Sizes
Small / Medium / Large / X-Large
Extreme Testing Conditions
Performs under temperature between 160°F (71°C) and -60°F (-51°C); Performs after 3 hours sea water immersion
Configurations
100% Boltless (Durability Verified)
Use
Training; Extreme Outdoor

Available Colors

Foliage Green
Olive Green
Sniper Black
Desert Tan
Coyote Brown

Available Cuts

High-Cut
Mid-Cut
Regular-Cut

Shell Info

Shell Thickness
0.1" (2.5 mm)
Finished Shell Nominal Weight*
Medium 0.77 lbs. / 0.35 Kg; Large 0.81 lbs. / 0.37 Kg; X-Large 0.87 lbs. / 0.4 Kg

* High-cut shell

System Info

Finished Helmet Nominal Weight**
Medium 1.2 lbs. / 0.55 Kg; Large 1.25 lbs. / 0.57 Kg; X-Large 1.3 lbs. / 0.6 Kg
Fully-Loaded High-Cut Nominal Weight***
Medium 1.65 lbs. / 0.75 Kg; Large 1.7 lbs. / 0.78 Kg; X-Large 1.8 lbs. / 0.81 Kg

** A High-cut helmet installed with retention and suspension systems *** Special Command configuration: the complete kit, with ASR side-rails, NVG Shroud and Operational Loop System

System Capabilities Checklist

Environmental Performance

Blunt Impact
Compression Resistance
Flammability
Shock absorption *
Resistance for penetration *
Advanced Boltless Adhesive System

Compatibility & Add-ons*

Universal side-rails
NVG Mount
Operational Loop System
Counterweight
Camouflage Cover
Strap Extenders
Visor / Goggles
Communications / Ear Protection
Gas Mask
Carrying Bag

* In accordance with ArmorSource technical specifications and applicable standards

How to Fit Your Helmet

Getting the right fit is important for performance and comfort. Use a tape measure and caliper to take measurements. The wearer MUST be seated in an upright position for proper fitting. See the illustrations for correct measuring points.

NOTE: If any measurement falls on the dividing line between sizes, select the larger size.

Head Length
Head Width
Circumference

Measure completely around head

Helmet Size
Head Length
Head Width
Circumference
Small
UP TO 7¼" / 184 mm
UP TO 6½" / 162 mm
UP TO 21¼" / 538 mm
Medium
7¼" / 184 mm to 7¾" / 198 mm
UP TO 6½" / 162 mm
21¼" / 538 mm to 22½" / 573 mm
Large
7¾" / 198 mm to 8¼" / 210 mm
UP TO 6½" / 162 mm
22½" / 573 mm to 23½"/ 597 mm
Extra-Large
8¼" / 210 mm and over
6½" / 162 mm and over
23½"/ 597 mm and over
